Johnson Controls HE-69S30NP-02 Humidity Element and Temperature Sensor

Johnson Controls HE-69S30NP-02 Humidity Element and Temperature Sensor delivers precise humidity sensing and temperature measurement for new HVAC systems. Built around a silicone temperature sensor and designed for duct mounting, it accepts 14–30V DC or 20–30V AC and provides scalable outputs of 0–10V DC or 0–5V DC with a 5–10V operating window.

With broad operating specs, this unit handles 0–100% relative humidity and 0–60°C ambient temperature, making it versatile for control panels, air handlers, and environmental monitoring. It carries performance approvals for UL, CE, C-Tick, and EMC, ensuring reliable integration into compliant systems. The compact housing combines a white plastic cover with a dark gray body and a probe for accurate sensing in tight spaces.

• Output options: 0–10V DC or 0–5V DC, up to 25 mA (minimum 3 mA) for flexible control integration.
• Power and communication: 14–30V DC or 20–30V AC input; 5–10V DC minimum-to-maximum output range.
• Environment: Operating humidity 0–100% RH; temperature 0–60°C; suitable for duct mounting.
• Electrical & mounting: 3/2-position screw terminal block; 16–24 AWG wires; UL, CE, C-Tick, EMC approved.
• Physical: Size 3.25" W × 8.27" D × 3.28" H; white cover with dark gray housing and probe.
