Allanson Transformers 2714-655-G Gas Transformer

Introducing the Allanson 2714-655-G Gas Transformer, a high-performance gas transformer engineered for reliable voltage conversion in residential, commercial, and industrial settings. This unit delivers a 275 V AC primary and a 12,000 V AC secondary at 60 Hz, providing safe, efficient operation for gas furnaces and related equipment. With a mid point ground ferromagnetic core and an internal junction box, it’s designed for sturdy performance and easy installation. The Rajah connector terminal and compact 1/4 inch-20 TPI x 1 inch stud mounting ensure secure connections in tight spaces.

Key specs and features are tailored for demanding environments, including robust voltage ratings and reliable performance across temperature and humidity ranges.

• Primary voltage: 275 V AC
• Secondary voltage: 12,000 V AC
• Frequency: 60 Hz
• Terminal type: Rajah Connector
• Mounting: 1/4 Inch-20 TPI x 1 Inch Stud
• Core design: Ferromagnetic, Mid Point Ground
• Junction box: Internal
• Poles: 2
• Operating voltage: 120 V AC
• Loading air gap: 1/8 to 3/16 Inch
• Temperature rating: Storage -40 to 80°C; Operating -30 to 40°C
• Humidity: 90% RH
• Applications: Residential, Industrial, Commercial Gas Furnace
