Amtrol ST-60V Thermal Expansion Tank

The Amtrol ST-60V Thermal Expansion Tank is a vertical stand unit designed for reliable pressure management in closed potable water systems. This 34-gallon tank features 22" diameter by 30" height with 3/4 inch female threaded inlet/outlet connections for easy integration.

Constructed with a urethane top-coated steel tank and an antimicrobial inner lining, it protects water quality while resisting corrosion. The heavy-duty butyl diaphragm, factory pre-charged air at 40 PSIG, and a temperature rating up to 200°F with a pressure rating up to 150 PSIG ensure durable expansion control in potable applications.

Designed to meet industry standards, it is IAPMO R&T and NSF/ANSI 61 compliant, ISO 9001 certified, and lead-free. The closed potable water system benefits from built-in features like a projection welded air valve, turbulator water circulator, and stainless steel system connection.

• 3/4" female threaded inlet/outlet connections
• 34-gallon capacity; 22" diameter x 30" height
• Heavy-duty butyl diaphragm; factory pre-charged air 40 PSIG
• Antimicrobial inner lining; urethane top-coated steel tank
• Projection welded air valve, turbulator water circulator, stainless steel system connection
• Lead-free; NSF/ANSI 61 compliant; IAPMO R&T; ISO 9001
• 1-year warranty
