ASCO EF8210G002 Solenoid Valve

The ASCO EF8210G002 Solenoid Valve is a rugged 2-Way, pilot-operated, diaphragm-based valve designed for precise control of air, water, and oil. It features a 1/2 inch threaded port connection on both sides and a durable brass body, with a versatile NEMA enclosure for harsh environments. Operating at 24 V DC, this valve delivers reliable performance in general service, dust collection systems, heating equipment, and combustion applications.

With its NEMA-rated enclosure (RedHat II) and robust seals, this solenoid valve is built to endure challenging industrial settings. Key specifications include pressure handling of 5–200 PSI for air, 150 PSI for water, and 135 PSI for oil; a maximum temperature rating of 180°F (fluid); Cv value of 4; and vertical/upright mounting compatibility. Media coverage spans air, water, and oil.

• 2-Way, pilot-operated diaphragm design for reliable, tight shut-off
• Brass body with 1/2" threaded port connections for easy integration
• NEMA enclosure compatibility: 1/2/3/3S/4/4X/6/6P/7/9, RedHat II
• Low power consumption: 6.1 W AC / 11.6 W DC
• Sealed with NBR/PTFE seals; robust cores: stainless steel and copper/silver shading coil
• UL, CSA, and CE listed for global compliance
