ASCO H10B620B5F1F26 Electro-Hydraulic Valve Actuator

The ASCO H10B620B5F1F26 Electro-Hydraulic Valve Actuator is a rugged, 2-Position actuator designed for precise control in heating and processing systems. Employing a solenoid, slow-opening operation and a 120 Volt AC supply, this unit delivers reliable performance across furnaces, dryers, dehydrators, conversion burners, heaters, and other industrial and commercial burners.

Key specs include 1.32 A at 60 Hz with a 158 VA power rating, operating temperature from -40 to 150 deg F, and a non-field adjustable limit switch with SPDT contacts rated up to 1800 VA. The actuator also includes a proof of closure switch for safety verification. Approved by UL, FM, and CSA, it is built to perform in demanding environments.

• Type: 2-Position Electro-Hydraulic Valve Actuator
• Operation: Solenoid, slow-opening
• Electrical: 120 VAC, 60 Hz, 1.32 A, 158 VA
• Limit Switch: Non-field adjustable, SPDT, 1800 VA
• Temperature Range: -40 to 150 deg F
• Approvals: UL, FM, CSA
• Includes: Proof of Closure Switch
• Applications: Furnace, Dryer, Dehydrator, Conversion Burner, Heater, Industrial & Commercial Burner
