ASCO K3A562V Gas Shut-Off Valve
ASCO K3A562V Gas Shut-Off Valve
Low stock: 2 left
Couldn't load pickup availability
SKU:65623
View full details
![ASCO K3A562V Gas Shut-Off Valve — New England Supply House spec card [NESH-SPEC-CARD-V2]](http://newenglandsupplyhouse.com/cdn/shop/files/spec-9032645312734.png?v=1782833802&width=1445)
The ASCO K3A562V Gas Shut-Off Valve is a reliable 120V, two-way normally closed solenoid valve designed for safe gas shutoff in residential and commercial applications. With 1" NPT connections, it supports versatile piping and easy integration. Rated up to 755,000 BTU and a maximum of 1.5 psi, it delivers dependable performance under demanding gas flow conditions.
This gas solenoid valve features a true NC (normally closed) configuration for a safe default state, ensuring gas is shut off when power is removed. Built for durability, it is well-suited for control of gas lines in furnaces, boilers, dryers, and other gas-fired equipment where reliable shutoff is critical.
- 120V coil designed for standard electrical supply and easy wiring integration
- 2-way NC operation provides a safe default shutoff in all power states
- 1" NPT ports offer versatile, quick installation with common piping sizes
- High capacity up to 755,000 BTU, suitable for demanding gas systems
- Low to moderate inlet pressure with a maximum 1.5 psi rating ensures compatibility with typical gas lines
Specifications
| Type | 2-Way, High Pressure Direct Acting, Piloted Operated |
|---|---|
| Pressure Rating | 0 to 1.5 PSI (Fuel Gas) |
| Temperature Rating | 77 Deg F (Fluid) |
| Input Supply | 120 Volt AC at 60 Hertz |
| Application | Combustion, Heating Equipment, Commercial and Industrial Gas Burner |
| Body Material | Die-Cast Aluminum |
| Port Connection | 1 Inch Threaded x 1 Inch Threaded |
| Standards | UL, CSA (Canada and US), FM |
| Enclosure Type | NEMA 1 |
| Includes | NBR Seal and Disc, 302 Stainless Steel Washer, 305 Stainless Steel Core Tube, 430F Stainless Steel Core and Plugnut, Core Guide, 302F Stainless Steel Spring, Copper Shading Coil, Cork Body Gasket, Zinc Plated Steel Pipe Plug, Orifice |
| Media | Fuel Gas |
| Valve Position | NC |
| Mounting Details | Horizontal/Upright Installation |
