Belimo TFB120 Damper Actuator

Belimo TFB120 Damper Actuator

$252.17 USD
$252.17 USD
Sale Sold out
Shipping calculated at checkout.

Low stock: 2 left

292447

View full details

The Belimo TFB120 Damper Actuator is an ON/OFF damper actuator designed for direct-coupled, spring-return operation. It delivers reliable HVAC control across a range of applications.

This model runs on 100–240 VAC (50/60 Hz), consuming 2.5 W running and 1.3 W holding, with a torque of 22 in-lb and a 95° rotation. Its NEMA 2 / IP42 enclosure protects the actuator in typical HVAC environments, while a 1/4"–1/2" shaft fits common damper linkages. A 3 ft 18 AWG appliance cable with a 1/2" conduit connector simplifies field wiring.

  • ON/OFF with spring-return operation for fail-safe positioning
  • Direct-coupled design simplifies installation and linkage
  • Wide voltage range 100–240 VAC (50/60 Hz) for global compatibility
  • Adequate torque and travel 22 in-lb, 95° rotation
  • Rugged enclosure NEMA 2 / IP42 rated
  • Quality and compliance UL (US/Canada), UL 60730, CE, CAN/CSA E60730, ISO 9001

Specifications

TypeON/OFF, Direct Coupled
Size3 Inch Width x 3.3 Inch Depth x 6.28 Inch Height
Voltage Rating100 to 240 Volt AC
Power Rating2.5 Watt (Running), 1.3 Watt (Holding)
Frequency50/60 Hertz
ApplicationHVAC System
ApprovalsUL (Canada and US), UL 60730, CE, CAN/CSA E60730, ISO 9001
EnclosureNEMA 2, IP42
Operation TypeSpring Return
Angle of Rotation95 Degree
Torque22 Inch-Pound
Shaft Diameter1/4 to 1/2 Inch
Operating Temperature-22 to 122 Deg F
Supply Connection3 Foot 18 AWG Appliance Cable with 1/2 Inch Conduit Connector
Max AC Voltage240 Volt
Minimum Ac Voltage100 Volt
