Bell & Gossett 790-3/4-30 Pressure Relief Valve

The Bell & Gossett 790-3/4-30 Pressure Relief Valve delivers reliable overpressure protection for heating boiler systems. This type pressure relief valve features a bronze body, 3/4 inch inlet and 3/4 inch outlet, and threaded end connections for straightforward installation. With a set pressure of 30 PSIG and a maximum pressure rating of 125 PSIG, it safeguards equipment and piping from dangerous pressure excursions while maintaining efficient boiler operation. Rated for up to 250°F, the valve is ASME compliant and built to endure demanding heating applications. Guided by a diaphragm actuation mechanism, it provides smooth, dependable response as pressure rises, delivering a nominal capacity of 790,000 BTU/hour for medium to large boiler loads.

• Inlet: 3/4" | Outlet: 3/4" | End Connections: Threaded x Threaded
• Bronze body for durability and corrosion resistance
• Set pressure: 30 PSIG; Pressure rating: 125 PSIG
• Temperature rating: 250°F
• Actuation: Diaphragm
• End-to-end distance: 2-9/16"
• Application: Heating boiler
• ASME compliant
• Nominal capacity: 790,000 BTU/hour
