Bell & Gossett FB-38TU Pressure Reducing Valve

Bell & Gossett FB-38TU Pressure Reducing Valve offers dependable downstream pressure control for potable water systems. This diaphragm-actuated valve features a brass body, a 1/2 inch nominal size, and end connections that are threaded union or soldered on both sides, for flexible installation.

It maintains a downstream pressure range of 10 to 25 PSIG with a standard factory setting of 12 PSIG, making it ideal for balancing supply pressure in both residential and light commercial applications. The unit includes a removable strainer and a low inlet pressure check valve for added protection, plus a robust 125 PSIG maximum working pressure and a 225°F temperature rating.

Designed for potable water, the valve is lead-free and compliant with ANSI/NSF 372 and CSA standards. The compact hardware fits tight install spaces, with an end-to-end distance of 4-31/32 inches.

• Diaphragm-actuated design for precise, stable regulation
• 1/2 inch nominal size with threaded union/soldered ends on both sides
• Brass body and lead-free construction
• Removable strainer and low inlet pressure check valve
• Downstream 10–25 PSIG with factory setting 12 PSIG
• 125 PSIG maximum pressure and 225°F temperature rating
• ANSI/NSF 372, CSA compliant for potable water safety
• End-to-end distance 4-31/32 inches
