Conbraco 1420508 Steam Boiler Safety Valve

The Conbraco 1420508 Steam Boiler Safety Valve delivers reliable overpressure protection for commercial and industrial boilers. This 1-Piece lever handle valve is designed for low pressure steam systems and provides quick, dependable operation in demanding environments.

With 2-inch inlet and 2-inch outlet connections and end connections described as male threaded x female threaded, it ensures a secure, leak-free installation. The valve is set to a standard pressure of 15 PSIG, offering precise control for safe boiler operation.

Constructed with a bronze body (ASTM B584) and a stainless steel spring, it resists corrosion in challenging heating applications. The chrome-plated seat, PTFE-coated disc, and EPDM O-ring deliver a positive seal and long service life, even under frequent cycling.

Standards and applicability: ASME, ISO 9001, CRN 0G8547.5C. This valve is suitable for commercial and industrial heating boilers and supports up to 3150 pounds per hour.

• 2" inlet and 2" outlet with end connections: male threaded x female threaded
• 1-piece lever handle for quick, reliable operation
• Bronze body (ASTM B584) with rust-proofed stainless steel spring
• Chrome-plated seat and PTFE-coated disc with EPDM O-ring for a positive seal
• Set pressure 15 PSIG; CRN-listed; ASME and ISO 9001 certified
• Capacity up to 3150 pounds per hour
