Erie Controls VT2417G23A020 Zone Valve Body Assembly

VT2417G23A020 Zone Valve Body Assembly delivers precise 2‑way control for hydronic heating and cooling systems. This 1-inch valve features soldered x soldered end connections, a 2‑position, spring-return actuator for general close-off, and a normally open (NO) position. Built with a forged brass body and nickel-plated brass stem, it handles hot and chilled water and glycol.

Valve timing and control specs ensure dependable operation: 25 seconds full open to full close at 60 Hz, 30 seconds at 50 Hz, or 9 seconds with spring return. It runs on 24 V AC at 50/60 Hz and is rated for 32 to 200°F (fluid). Close-off pressure rating 25 psi; static pressure up to 300 psi. Media handled includes hot water, chilled water, and glycol. ANSI Class IV is standard for this valve.

• 2‑Way, 1" nominal size
• End connections: soldered x soldered
• Actuation: 2‑position, spring-return with fail-safe
• Normally open (NO) position with full-open/close timing
• Forged brass body with nickel-plated brass stem and Buna N paddle
• Flow capacity: 7.5 Cv
• Electrical: 24V AC, 18" lead
• Media: hot/chilled water, glycol
• Operating temp: 32–200°F; humidity 5–95% non-condensing
• Applications: heating and cooling; ANSI Class IV
