Erie Controls VT3315G13B020 Zone Valve Body Assembly

Zone Valve Body Assembly from Erie Controls VT3315G13B020 delivers precise flow control for heating and cooling systems. This 3-Way valve features a 3/4 inch nominal size with soldered x soldered connections and a 2-Position, spring-return actuation for reliable general close-off. Application heating and cooling systems benefit from its fail-safe operation and easy manual override for on-site service.

Built with a forged brass body, nickel-plated brass stem, brass seat, and Buna N paddle, it provides durable, leak-tight performance. It is rated for 32 to 200 Deg F fluids and up to 40 psi close-off (300 psi static), and is suitable for hot or chilled water and glycol. The valve timing is 25 seconds at 60 Hz (30 seconds at 50 Hz) with a 9-second full-open to full-close spring return.

Electrical and installation specs include 110/120 Volt AC at 60/50 Hz, 18 inch lead, and both horizontal and vertical mounting. It complies with ANSI Class IV standards and offers a 5 Cv flow capacity, making it ideal for precise zone control in HVAC systems.

• 3-Way valve design with 3/4" nominal size and soldered connections
• 2-Position, spring-return actuation for fail-safe operation
• Forged brass body with nickel-plated stem and Buna N paddle; hysteresis synchronous motor for long life
• Suitable for hot/chilled water and glycol; 32–200 Deg F, 40 psi close-off / 300 psi static
• ANSI Class IV, 5 Cv flow; 18" electrical lead; manual override lever
