Hoffman FT015H-3/4 Steam Trap

The Hoffman FT015H-3/4 Steam Trap is a robust thermostatic steam trap designed for efficient condensate handling in institutional and commercial/industrial heating systems. This 3/4 inch nominal size unit blends a thermostatic and float mechanism to deliver fast response, reliable operation, and long service life in demanding steam applications.

End connection is Threaded x Threaded, and the durable cast iron body thrives in high-temperature steam service. With a temperature rating 406°F and a pressure rating 250 PSI (differential 15 PSI), it provides precise condensate removal across varying loads while handling steam media with confidence.

Designed for versatility, the FT015H-3/4 supports a 4-port design (2 inlet / 2 outlet) to accommodate multiple piping configurations in institutional, commercial, and industrial heating systems.

• Stainless steel valve pin and seat for corrosion resistance and long life
• Float/lever assembly with cage for reliable float-assisted operation
• Thermal element thermostatic air vent improves air elimination and startup response
• Grade 5 cover bolt for secure, durable enclosure
• Cast iron body designed for rugged steam service
• 4-port design enabling flexible inlet/outlet configurations
