Honeywell Commercial H7725B2006 Duct Humidity Sensor

Honeywell Commercial H7725B2006 Duct Humidity Sensor delivers precise, repeatable humidity sensing for commercial HVAC ducts. Built for accuracy and stability as a trusted humidity and temperature sensor, it supports reliable monitoring in demanding environments.

Power options include 18-28 VAC or 18-40 VDC, while output is selectable between 0-5 VDC or 0-10 VDC with a maximum of 5/10 VDC. The device provides a 4-20 mA current output (min 4 mA, max 20 mA) with an accuracy of ±2%.

Operating range covers 0-95% RH and temperatures from -10 to 140 °F. Its compact duct-mount enclosure measures 3" W x 7/8" D x 4-9/16" H, making installation straightforward in tight duct spaces.

Applications focus on humidity and temperature sensing for industrial HVAC, commercial buildings, and data centers, delivering stable performance and long-term reliability.

• Power: 18-28 VAC or 18-40 VDC
• Output: 0-5 VDC or 0-10 VDC (selectable); current: 4-20 mA
• Accuracy: ±2%
• Humidity range: 0-95% RH
• Temperature range: -10 to 140 °F
• Mounting: duct
• Size: 3"W x 7/8"D x 4-9/16"H
