Honeywell Commercial M6184F1014 Actuator Motor

The Honeywell Commercial M6184F1014 Actuator Motor is a versatile 24V AC damper actuator built for commercial HVAC systems. With non-spring return operation and 90-degree rotation, it delivers precise, reliable damper control across a broad temperature range (-40 to 150°F). Rated for 150 in-lb torque and housed in a rugged NEMA 3 enclosure, this actuator tolerates demanding environments while ensuring smooth, accurate positioning.

Its compact footprint supports easy installation with foot mounting and quick-connect terminals, while the included auxiliary switch provides additional control options. Designed for dampers, it meets UL (Canada and US) and CE safety standards and is RoHS compliant, highlighting safety and environmental responsibility. The unit operates at 24 V AC, 50/60 Hz, with a nominal 30–60 second response time and a compact size of 5-1/2 inch width x 7-5/16 inch depth x 6-7/16 inch height. This combination makes installation faster and system integration simpler for new builds and retrofits.

• Type: Electric, Floating
• Operation: Non-Spring Return
• Voltage: 24V AC
• Frequency: 50/60 Hz
• Power: 15 VA
• Torque: 150 in-lb
• Angle of Rotation: 90°
• Enclosure: NEMA 3
• Mounting: Foot Mount
• Connection: Quick Connect Terminal
• Nominal Time: 30–60 seconds
• Includes: 2 Auxiliary Switch
• Approvals: UL (Canada and US), CE; RoHS Compliant
• Application: Damper
