Honeywell Commercial M7284Q1009 Damper Actuator

Honeywell Commercial M7284Q1009 Damper Actuator is an electric, modulating damper actuator designed for precise HVAC control. This 120V AC unit draws 0.24 A and delivers 23 W of power to provide 150 inch-pounds of torque through a 90-degree rotation.

The die-cast aluminum body sits in a durable NEMA 3 enclosure, suitable for indoor or outdoor service with an operating temperature range of -40 to 150°F. It supports damper and valve control with a 4–20 mA control signal and clockwise rotation. With foot mounting and screw-terminal connections, installation is quick and secure.

Includes transformer, screw terminal adapter, and two auxiliary switches for enhanced integration. UL (Canada and US) and CE approvals, plus RoHS compliance, ensure reliable, standards‑conforming operation in commercial systems.

• Modulating control for precise air flow and zoning management
• Input: 120 VAC; current: 0.24 A; power: 23 W
• Torque: 150 in-lb; Rotation: 90 degrees; Rotation direction: Clockwise
• Rugged die-cast aluminum body in a NEMA 3 enclosure
• Operating temperature: -40 to 150°F
• Mounting: Foot mount; connections: Screw terminals
• Control signal: 4–20 mA
• Includes transformer, screw terminal adapter, and (2) auxiliary switches
• UL/cUL, CE, RoHS compliant
