Honeywell Commercial M7285C1009 Damper Actuator

The Honeywell Commercial M7285C1009 Damper Actuator is an electric modulating damper actuator with spring-return operation, designed for reliable control of dampers and valves in commercial HVAC systems. It runs on 120 VAC, consumes 28 W, and delivers 60 in-lb of torque through a precise 90-degree rotation. The rugged die-cast aluminum body lives in a NEMA 3 enclosure, built to withstand harsh environments, with an ambient range from -40 to 150°F. Controlled by a 4-20 mA signal and rotating clockwise, this unit offers a compact footprint: 5-1/2 in W x 8-3/4 in D x 6-7/16 in H. It uses screw terminals for easy wiring and features UL (Canada and US), CE, and RoHS compliance for modern HVAC applications. Nominal timing is 30 to 60 seconds, making it suitable for efficient, responsive damper and valve actuation. Includes transformer, screw-terminal adapter, and (2) auxiliary switches to simplify installation and integration with building controls.

• Voltage: 120 VAC | Power: 28 W | Current: 0.28 A | 50/60 Hz
• Rotation: 90° clockwise | Torque: 60 in-lb
• Operation: Spring-return | Control signal: 4-20 mA
• Enclosure: NEMA 3 | Construction: Die-cast aluminum | Temperature: -40 to 150°F
• Dimensions: 5-1/2 in W x 8-3/4 in D x 6-7/16 in H
• Mounting and wiring: Foot mount, screw-terminal connections
• Includes: Transformer, screw-terminal adapter, and (2) auxiliary switches
• Compliance: UL (Canada and US), CE, RoHS
