Honeywell Commercial M7294Q1007 Damper Actuator

The Honeywell M7294Q1007 Damper Actuator is a high-performance electric, modulating actuator designed for precise damper control in commercial HVAC installations. Operating at 120 Volt AC with a 50/60 Hz power supply, this non-spring return unit delivers repeatable positioning across a 90-degree rotation, ideal for modulating airflow.

Constructed with a durable die-cast aluminum body, it is mounted in a NEMA 3 enclosure to ensure reliable performance in dusty or damp environments. The actuator ships with a transformer and screw terminal adapter, and includes two auxiliary switches for expanded control options in larger systems.

• Type: Electric, Modulating
• Operation: Non-Spring Return
• Voltage: 120 VAC
• Frequency: 50/60 Hz
• Torque: 300 in-lb
• Angle of Rotation: 90°
• Enclosure: NEMA 3
• Mounting: Foot Mount
• Connection: Screw Terminal
• Includes: Transformer and Screw Terminal Adapter; (2) Auxiliary Switch
• Dimensions: 5-1/2 in W x 7-5/16 in D x 6-7/16 in H
• Operating Temp: -40 to 150°F
• Approvals: UL, CE; RoHS Compliant

UL and CE approvals, along with RoHS compliance, ensure safety and sustainability, while the compact footprint and solid mounting options make this damper actuator a trusted choice for commercial HVAC systems.
