Honeywell Commercial M836A1042 Actuator Motor

Honeywell Commercial M836A1042 Actuator Motor is a 24 Volt AC SPST, 2-Position damper actuator designed for residential and light commercial HVAC applications. With Spring Return operation and a 75-degree rotation, this compact unit delivers reliable opening and closing action for precise damper control in heating and cooling systems.

Key specifications and performance: 24 VAC supply; current draw 1.85 A during opening and 0.6 A in holding; power 28 W opening, 8.5 W holding; torque 20 in-lb; timing 30 seconds; operating temperature range 32 to 125°F; size 4-5/8" W x 3-3/4" D x 4-1/2" H; angle of rotation 75°; UL approved for safe, compliant installation.

• Type SPST, 2-Position operation
• Spring Return design for dependable damper positioning
• 24 VAC, 60 Hz operation with screw-terminal connection
• 75° rotation and 20 in-lb torque for versatile damper control
• Foot mount mounting type for solid installation
• Compact footprint suitable for residential and light commercial HVAC dampers
• UL approved for safety and compliance
• 30-second timing ensures timely damper cycling
