Honeywell Commercial M8415A1004 Economizer Damper Actuator

The Economizer Damper Actuator from Honeywell (Model M8415A1004) is a 2-Position SPST actuator with Spring Return for precise damper control in HVAC systems. Operating on 24V AC with a 90-degree rotation, this UL-approved unit is built for reliable performance in commercial environments.

Designed for Foot Mount installation with Quick Connect Terminals, it features a durable plastic body and a compact footprint suitable for retrofit projects. This actuator is compatible with a wide range of economizer dampers, providing dependable operation across operating temperatures.

• Type: SPST, 2-Position
• Operation: Spring Return
• Voltage: 24V AC (Max 24V)
• Frequency: 50/60 Hz
• Power: 8 VA driving; 3 VA holding
• Torque: 25 in-lb
• Travel: 90 degrees
• Rotation: Counterclockwise
• Size: 5" W x 5-3/16" D x 4-1/2" H
• Body: Plastic
• Operating Temp: -25 to 125 F
• Application: HVAC System
• Mounting: Foot Mount
• Connection: Quick Connect Terminal
• Timing: 90 seconds
• Approval: UL

Designed to optimize energy efficiency and comfort, this actuator delivers dependable performance across seasonal changes.
