Honeywell Commercial M9184C1031 Actuator Motor

Honeywell Commercial M9184C1031 Actuator Motor delivers reliable, proportional control for commercial damper applications. Operating on 24V AC with 50/60 Hz power, this electric actuator provides precise 90-degree travel and 150 in-lb of torque for accurate damper positioning, with a nominal 30–60 second travel time.

Designed for rugged environments, it features a NEMA 3 enclosure, foot mounting, and quick-connect terminals for straightforward installation. The clockwise rotation and 15 VA driving power support fast, dependable damper control across HVAC systems. It is RoHS compliant with UL (Canada and US) and CE approvals.

• Proportional electric actuator with non-spring return
• Voltage: 24 VAC; Frequency: 50/60 Hz
• Torque: 150 in-lb; Angle of rotation: 90°; Rotation: Clockwise
• Enclosure: NEMA 3; Mounting: Foot mount; Connection: Quick-connect terminals
• Nominal time: 30–60 seconds
• Includes: 2 auxiliary switches
• Operating temperature: -40 to 150 °F
• Compliance: UL (Canada/US), CE, RoHS
