Honeywell Commercial ML7174A2001 Damper Actuator

Damper Actuator for HVAC systems, the Honeywell Commercial ML7174A2001 delivers precise control in commercial environments. This direct-coupled, non-spring return damper actuator operates on 24 Volt AC with a 50/60 Hz supply, delivering 70 inch-pounds of torque and a 90-degree rotation for accurate damper positioning.

Built for durability, the plenum-rated plastic body sits in a NEMA 1 enclosure and is UL and CSA approved for safe, reliable operation in indoor commercial environments. It accepts control signals from 2 to 10 VDC or 4 to 20 mA via screw terminals, with a 90-second timing that ensures controlled movement.

• Direct-coupled design for reliable operation
• 24 VAC, 50/60 Hz compatibility
• 70 in-lb torque for strong damper actuation
• 90° rotation for precise airflow control
• Plenum-rated plastic body with NEMA 1 enclosure
• UL and CSA safety approvals
• Screw-terminal wiring for easy installation
• Control signals 2–10 VDC or 4–20 mA
• Shaft compatibility 3/8" to 1/2" diameters
• Includes bag assembly for quick setup

Ideal for commercial HVAC systems requiring dependable damper actuation, long service life, and easy installation.
