Honeywell Commercial MS4104F1210 Damper Actuator

Honeywell Commercial MS4104F1210 Damper Actuator

$397.55 USD
$397.55 USD
Sale Sold out
Shipping calculated at checkout.

Low stock: 2 left

292798

View full details

The Honeywell Commercial MS4104F1210 Damper Actuator delivers precise 2-position control with fast acting SPST operation. This direct-coupled, spring-return actuator runs on 120 Volt AC (60 Hz) and provides 18 W driving power and 9 W holding power, with a driving current of 0.18 A and holding current of 0.11 A. It offers 30 in-lb torque across a 95° rotation for reliable damper positioning in fire and smoke applications. The unit features a sturdy aluminum body in a NEMA 1/IP40 enclosure, engineered for durability in commercial environments. Its 15-second timing ensures quick damper response, while the 1/2 inch shaft and compact dimensions (5.13" W x 3.32" D x 8.9" H) simplify mounting. UL 873, CUL C22.2, and C-Tick approvals confirm safety and compliance for regulated installations, and the design includes two auxiliary switches for expanded control and signaling needs.

  • 120 VAC, 60 Hz
  • 30 in-lb
  • 95°
  • NEMA 1, IP40, aluminum
  • 15 seconds
  • (2) Auxiliary Switches

Specifications

TypeSPST, Direct Coupled, 2-Position, Fast Acting
Size5.13 Inch Width x 3.32 Inch Depth x 8.9 Inch Height
Voltage Rating120 Volt AC
Current Rating0.18 Amp (Driving), 0.11 Amp (Holding)
Power Rating18 Watt (Driving), 9 Watt (Holding)
Frequency60 Hertz
ApplicationFire and Smoke
Body MaterialAluminum
ApprovalsUL 873, CUL C22.2, C-Tick
EnclosureNEMA 1, IP40
Operation TypeSpring Return
Angle of Rotation95 Degree
Torque30 Inch-Pound
Shaft Diameter1/2 Inch
Operating Temperature0 to 130 Deg F (Ambient)
Supply Connection32 Inch Color Coded Lead
Max AC Voltage120 Volt
