Honeywell Commercial MS7510A2008 Damper Actuator

The Honeywell Commercial MS7510A2008 Damper Actuator delivers reliable ON/OFF control for HVAC systems, combining a robust direct-coupled design with a spring-return mechanism. This SPDT, floating actuator supports both 24V AC/DC operation and a manual crank for quick site adjustments.

• Voltage and power: 24V AC/DC input; 14 VA driving, 5 VA holding
• Torque and rotation: 88 in-lb torque; 95° rotation
• Construction: Aluminum body; NEMA 2 enclosure
• Operation: Spring-return with manual crank; ON/OFF, SPDT, direct-coupled, floating
• Connection: Enclosed screw terminal strip
• Environment: -40 to 140°F ambient; 50/60 Hz
• Size and shaft: 3.94"W x 2.95"D x 9.72"H; shaft diameter 3/8"–1.06"
• Certifications: UL 873, CUL C22.2, CE, C-Tick
• Travel timing: 20 seconds

Designed for robust performance in commercial HVAC systems, this actuator provides precise damper positioning, easy installation, and reliable operation across industrial environments. The aluminum body, NEMA 2 enclosure, and multiple safety approvals help ensure long service life and seamless integration with existing control schemes.
