Honeywell Commercial MS7520A2205 Damper Actuator

Honeywell Commercial MS7520A2205 Damper Actuator

$640.68 USD
$640.68 USD
Sale Sold out
Shipping calculated at checkout.

Out of stock

99471

View full details

The Honeywell MS7520A2205 Damper Actuator is a durable ON/OFF, SPDT, direct-coupled damper actuator engineered for reliable HVAC control. It runs on 24 VAC, offers spring-return operation with a manual crank, and delivers 95-degree rotation for precise damper positioning.

  • Type: ON/OFF, SPDT, Direct Coupled, Floating
  • Operation: Spring Return with Manual Crank
  • Electrical: 24 VAC; 50/60 Hz; 16 VA Driving / 5 VA Holding; Output 2–10 VDC
  • Performance: 175 in-lbs Torque; 95° Rotation; 90-Second Timing
  • Enclosure & Build: NEMA 2 enclosure; Aluminum body; Shaft 3/8" to 1.06" diameter
  • Controls & Compliance: Enclosed Screw Terminal Strip; UL 873, CUL C22.2, CE, C-Tick
  • Application & Accessories: HVAC system; Includes two auxiliary switches

Ideal for commercial HVAC applications, the Honeywell MS7520A2205 Damper Actuator delivers reliable position control and easy integration with existing 2–10 VDC control systems.

Specifications

TypeON/OFF, SPDT, Direct Coupled, Floating
Size3.94 Inch Width x 2.95 Inch Depth x 9.72 Inch Height
Voltage Rating24 Volt AC
Power Rating16 Volt Amp (Driving), 5 Volt Amp (Holding)
Frequency50/60 Hertz
ApplicationHVAC System
Body MaterialAluminum
ApprovalsUL 873, CUL C22.2, CE, C-Tick
EnclosureNEMA 2
Operation TypeSpring Return, Manual Crank
Angle of Rotation95 Degree
Torque175 Inch-Pound
Shaft Diameter3/8 to 1.06 Inch
Operating Temperature-40 to 140 Deg F (Ambient)
Output Signal2 to 10 Volt DC
Max AC Voltage24 Volt
