Honeywell Commercial MS8120F1002 Direct Coupled Actuator

Honeywell Commercial MS8120F1002 Direct Coupled Actuator

$605.97 USD
$605.97 USD
Sale Sold out
Shipping calculated at checkout.

Low stock: 4 left

66956

View full details

Direct Coupled Actuator Honeywell MS8120F1002 delivers fast acting, SPST, 2-position control for fire and smoke systems. This 24V AC actuator features spring-return operation and a manual crank, housed in a rugged aluminum body with a NEMA 2 / IP54 enclosure for reliable performance in challenging environments. With 175 in-lb of torque, a 95-degree swing, and 15-second actuation timing, it ensures precise, fail-safe operation in commercial fire and smoke control installations. Built to meet UL 873, CUL C22.2, CE, and C-Tick approvals, this actuator is designed for durable, long-life service in HVAC and safety applications.

  • Configuration: SPST, Direct Coupled, 2-Position
  • Power and timing: 24 VAC, 50/60 Hz, 15 second timing
  • Mechanical drive: 175 in-lb torque, 95° rotation
  • Protection: NEMA 2, IP54 enclosure, aluminum body
  • Operating features: Spring Return, Manual Crank
  • Approvals: UL 873, CUL C22.2, CE, C-Tick
  • Electrical connection: 40 Inch Non-Stick Jacketed Cable

Specifications

TypeSPST, Direct Coupled, 2-Position, Fast Acting
Size3.94 Inch Width x 2.95 Inch Depth x 10.67 Inch Height
Voltage Rating24 Volt AC
Power Rating45 Volt Amp (Driving), 10 Volt Amp (Holding)
Frequency50/60 Hertz
ApplicationFire and Smoke
Body MaterialAluminum
ApprovalsUL 873, CUL C22.2, CE, C-Tick
EnclosureNEMA 2, IP54
Operation TypeSpring Return, Manual Crank
Angle of Rotation95 Degree
Torque175 Inch-Pound
Shaft Diameter3/8 to 1.06 Inch
Operating Temperature-40 to 130 Deg F (Ambient)
Supply Connection40 Inch Non-Stick Jacketed Cable
Max AC Voltage24 Volt
