Honeywell Commercial V5011G1129 Globe Valve

Introducing the Honeywell V5011G1129 Globe Valve, a 3-inch nominal size globe valve engineered for reliable control in heating and air conditioning systems. This 2-way, stem-down-to-close, direct-acting valve is single-seated with a straight-through, linear-flow design that delivers precise valve performance. End connections are female threaded x female threaded, with an end-to-end distance of 8-7/8 inches and a female-threaded bonnet for straightforward installation and service.

Constructed for durability, the body is red brass while the stem and seat are stainless steel. The seal is a non-stick cone and the disc is carbon-loaded non-stick, providing smooth operation and reduced wear. It carries ANSI/ASME compliance and is rated Class 150 (static), 240 PSI at 150°F for water or 100 PSI at 337°F for steam.

Designed to integrate with a range of actuators and control equipment, it includes self-adjusting/spring-loaded packing and stainless steel plug/ball for long life. Key performance parameters: Cv 100, stem travel 3/4 inch, bonnet size 1-3/8 inch, maximum differential pressure 20 PSID. This valve is ideal for Heating/Air Conditioning Systems and supports a variety of actuator options (Q5001 Modutrol IV Motor, MP953 Pneumatic Coil Valve Actuator, and more).

• 3" nominal size, 2-way globe valve with stem-down-to-close design
• End connection: female threaded x female threaded
• End-to-end distance: 8-7/8 in; bonnet: 1-3/8 in
• Body: red brass; stem/seat: stainless steel; seals: non-stick cone
• Flow capacity: Cv 100; stem travel 3/4 in; max DP 20 PSID
• Inclusions: self-adjusting packing; stainless steel plug/ball
