Honeywell Commercial V5011N1057 Globe Valve

The Honeywell Commercial V5011N1057 Globe Valve is a precision control valve designed for reliable performance in steam, water, and glycol systems. This 2-way globe valve features electric or linear pneumatic direct-acting actuation, offering fast response and tight shutoff.

With a 3/4 inch nominal size and female threaded end connections, it fits standard piping in commercial HVAC and process lines. The valve features a red brass body, stainless steel stem, stainless steel seat, and brass plug assembly for durable, long-lasting operation at temperatures up to 248°F and pressures to 217 PSI.

Designed to meet ANSI/ASME standards, the V5011N1057 uses an up-closed stem, threaded bonnet, and a compact end-to-end distance of 3-1/4 inches, delivering reliable fit and easy maintenance in tight spaces.

Key specifications and components ensure solid performance across applications like steam, water, and glycol. Flow capacity is 7.3 Cv for smooth, controllable flow. Inclusions include brass ball, stainless steel seat, brass plug, stroke, bonnet, brass cartridge, and stainless steel trim.

• Nominal size: 3/4 inch
• End connections: Female threaded x Female threaded
• Actuation: Electric/Linear Pneumatic, Direct Acting
• Materials: Red brass body; stainless steel stem and seat; brass disc; stainless steel trim; non-stick seal
• Bonnet: Threaded; Stroke and bonnet included
• End-to-end distance: 3-1/4 inch
• Temperature/Pressure rating: 248°F at 217 PSI
• Flow capacity: 7.3 Cv
• Applications: Steam, Water, Glycol
• Standards: ANSI/ASME compliant
