Honeywell Commercial V5863A2046 Cartridge Globe Valve

Honeywell Commercial V5863A2046 Cartridge Globe Valve is a versatile 1/2 inch, 3-way globe valve designed for HVAC applications. With a stem-up to close and equal percentage flow, it delivers precise control for hot and chilled water in fan coil units, small re-heaters, and re-coolers.

Constructed for durability, the brass body houses a stainless steel stem with brass seats and discs for reliable shutoff. End connections are female soldered on all ports, and the bonnet is female soldered. The valve features an end-to-end distance of 3 inches, a temperature rating of 36 to 230°F, and a pressure rating of 235 PSI, making it suitable for demanding commercial environments.

Compatible with multiple cartridge actuators, this valve can be paired with M6410A1029, M6435A1004, M7410F1000, M7435F1001 cartridge actuators, or the MP958 pneumatic actuator to suit your control strategy.

• Nominal size: 1/2 inch
• Type: 3-way globe valve; cartridge globe valve; stem up to close
• End connections: Female soldered x Female soldered x Female soldered
• End-to-end distance: 3 inches
• Body: Brass; Stem: Stainless steel; Seat & Disc: Brass
• Temperature rating: 36–230°F
• Pressure rating: 235 PSI
• Flow capacity: 1.9 Cv
• Stem travel: 1/4 inch; Maximum differential pressure: 34 PSI
• Inclusions: Brass plug/ball/ cartridge; threaded plastic cover; manual handle; long stroke
• Applications: Hot and chilled water; Fan coil unit; Small re-heater and re-cooler
• Standards: ANSI Class IV; UL94-5V
• Used With: M6410A1029/M6435A1004/M7410F1000/M7435F1001 cartridge actuators; MP958 pneumatic actuator
