Honeywell Thermal Solutions FSG M9484E1017 Actuator Motor

Honeywell FSG M9484E1017 Actuator Motor delivers precise proportional control for dampers and auxiliary equipment in HVAC and industrial systems. This electric reversing actuator operates at 24 VAC with a 50/60 Hz input, providing reliable 15-watt power and 150 Inch-Pound torque across a 90-degree rotation.

With a NEMA 3 enclosure and a compact footprint (5.5" W x 7.3" D x 6.45" H), it's built for rugged performance in challenging environments. UL (Canada and US) and CE approvals ensure safe installation and compliance for commercial applications and retrofit projects.

Key specifications

• Type: Electric, Reversing, Proportional
• Operation: Non-Spring Return
• Voltage: 24 Volt AC; Frequency: 50/60 Hz
• Power/Torque: 15 Watt; 150 Inch-Pound
• Rotation: 90 Degree
• Enclosure: NEMA 3
• Dimensions: 5.5 Inch W x 7.3 Inch D x 6.45 Inch H; Shaft Diameter: 3/8 Square Inch
• Operating Temperature: -40 to 150 Deg F (Ambient)
• Applications: Damper, Auxiliary Equipment
• Approvals: UL (Canada and US), CE
• Connection: Quick Connect Terminal
• Nominal Time: 30 to 60 Second
