Honeywell Thermal Solutions FSG M9484E1033 Actuator Motor

Actuator Motor FSG M9484E1033 from Honeywell Thermal Solutions delivers precise, reliable control for dampers and auxiliary equipment. This electric, reversing, proportional actuator operates on 24 Volt AC and is designed with a non-spring return for accurate end positions in HVAC systems. The compact unit provides smooth modulation and quick response in demanding environments.

With a 90-degree travel and 150 in-lb of torque, it handles a wide range of damper applications. The rugged NEMA 3 enclosure protects against dust and moisture, while Quick Connect Terminals simplify wiring. UL and CE approved, this actuator is built for durable performance from -40 to 150°F.

• Type: Electric, reversing, proportional
• Operation: Non-spring return
• Voltage: 24 VAC
• Frequency: 50/60 Hz
• Power: 15 W
• Torque: 150 in-lb
• Angle of rotation: 90°
• Enclosure: NEMA 3
• Shaft diameter: 3/8 in square
• Operating temperature: -40 to 150°F
• Travel time: 30–60 seconds
• Approvals: UL, CE
• Connection: Quick Connect Terminal
• Applications: Damper, Auxiliary equipment
