Honeywell Thermal Solutions FSG M9484F1007 Actuator Motor

Honeywell Thermal Solutions FSG M9484F1007 Actuator Motor

$1,433.08 USD
$1,433.08 USD
Sale Sold out
Shipping calculated at checkout.

Low stock: 5 left

2332

View full details

Honeywell Thermal Solutions FSG M9484F1007 Actuator Motor is an electric, reversing, proportional actuator designed for dampers and auxiliary equipment. This 24 V AC, non-spring-return unit provides reliable proportional control with 90-degree travel, ideal for HVAC damper applications in demanding environments.

Built for durability, it combines solid torque and efficient operation in a compact enclosure. The actuator’s UL and CE approvals ensure safe installation across North America and beyond, while the quick-connect terminal simplifies wiring for fast commissioning.

  • Voltage: 24 VAC; Frequency: 50/60 Hz
  • Torque: 150 in-lb
  • Power: 15 W
  • Rotation: 90 degrees; Nominal time 30–60 seconds
  • Enclosure: NEMA 3
  • Shaft: 3/8 in square
  • Temperature: -40 to 150°F (-40 to 66°C)
  • Applications: Damper, Auxiliary equipment
  • Approvals: UL (Canada/US), CE
  • Connection: Quick Connect Terminal

Specifications

TypeElectric, Reversing, Proportional
Size5.5 Inch Width x 7.3 Inch Depth x 6.45 Inch Height
Voltage Rating24 Volt AC
Power Rating15 Watt
Frequency50/60 Hertz
ApplicationDamper, Auxiliary Equipment
ApprovalsUL (Canada and US), CE
EnclosureNEMA 3
Operation TypeNon-Spring Return
Angle of Rotation90 Degree
Torque150 Inch-Pound
Shaft Diameter3/8 Square Inch
Operating Temperature-40 to 150 Deg F (Ambient)
Max AC Voltage24 Volt
