Honeywell Thermal Solutions FSG M9494D1000 Actuator Motor

The Honeywell FSG M9494D1000 Actuator Motor is a high-performance electric actuator motor designed for damper and auxiliary equipment control. This reversing, proportional actuator operates at 24 Volt AC with a 50/60 Hz input, delivering precise motion for HVAC applications. With 15 Watts of power and 150 inch-pounds of torque, it delivers dependable 90-degree rotation from a compact 5.5" W x 7.3" D x 6.45" H enclosure. It features a non-spring return design for controlled positioning and a robust NEMA 3 enclosure for outdoor or damp environments. The shaft is 3/8" square, compatible with quick-connect terminals, and the nominal travel time is 30 to 60 seconds. Ideal for damper control and auxiliary equipment, this actuator is built to perform reliably in commissioning and continuous operation, backed by UL (Canada and US) and CE approvals.

• Voltage: 24 VAC, 50/60 Hz; Power: 15 W
• Torque & Travel: 150 in-lb torque; 90° rotation; 30–60 second nominal time
• Design: Reversing, proportional, non-spring return; NEMA 3 enclosure
• Physicals: 5.5" W × 7.3" D × 6.45" H; shaft 3/8" square; quick-connect terminals
• Applications: Damper and auxiliary equipment control in HVAC systems
• Approvals: UL (Canada/US) and CE
