Honeywell Thermal Solutions FSG Q7800B1003 Terminal Universal Wiring Sub-Base

The Honeywell Thermal Solutions FSG Q7800B1003 Terminal Universal Wiring Sub-Base is engineered for reliable, organized wiring in control panels. This wall-mount sub-base is compatible with the 7800 Series relay module and the S7830 expanded annunciator, providing a clean, scalable wiring platform.

Designed for indoor use, it carries a NEMA 1 enclosure rating and is UL and CSA approved, ensuring dependable performance across installations. It features 22 terminals and a precise terminal screw torque of 12 in-lb typical, 13 in-lb maximum to maintain secure connections. The compact footprint helps maximize panel space while delivering robust reliability.

• 22 terminals for versatile wiring
• Wall-mount design for easy installation
• NEMA 1 enclosure protection
• Terminal screw torque 12 in-lb typical, 13 in-lb maximum
• Dimensions 4-31/32 in W x 1-13/32 in D x 4-31/32 in H
• Approvals UL and CSA listed
• Temperature range -40 to 140°F (shipping and storage)
