Honeywell Thermal Solutions FSG Q7800B1011 Terminal Universal Wiring Sub-Base

Terminal Universal Wiring Sub-Base (FSG Q7800B1011) from Honeywell Thermal Solutions is engineered for versatile, reliable wiring of 7800 Series relay systems. This wall-mount sub-base supports the 7800 Series Relay Module and S7830 Expanded Annunciator, delivering a compact 22-terminal solution for organized control panels.

This sub-base features a NEMA 1 enclosure and a compact footprint: 4-31/32" W x 3" D x 4-31/32" H, with a terminal count of 22. Designed for rugged industrial environments, it accommodates a terminal screw torque of 12 in-lb typical and 13 in-lb maximum, ensuring secure, vibration-resistant connections. Operating temperature range from -40 to 140°F (shipping and storage) adds versatility for various installations. It is UL and CSA listed for reputable safety and compliance.

• 22-terminal universal wiring sub-base
• Wall-mount design compatible with 7800 Series Relay Module and S7830 Expanded Annunciator
• NEMA 1 enclosure for indoor panel use
• Terminal screw torque: 12 in-lb typical, 13 in-lb max
• Dimensions: 4-31/32" W x 3" D x 4-31/32" H
• Temperature range: -40 to 140°F (shipping/storage)
• UL and CSA approvals for safe operation
