Honeywell Thermal Solutions FSG RM7800E1010 Burner Control

The Honeywell RM7800E1010 Burner Control is a microprocessor-based integrated solution that manages burner sequencing, flame supervision, and self-diagnostics for reliable ignition across fuel types (gas, oil, coal, or combination fuels).

Designed for single-burner systems, this 120 VAC control delivers precise timing for pilot and main flame establishment, including a 4/10 second pilot establish period and a 10/15 second main flame window. It supports automatic burner firing with pre-ignition, early spark termination, and proven purge sequences (LHL-LF and HF) to ensure safe, consistent operation.

Key specifications include compact dimensions (5" W x 5-1/4" D x 5" H), interlock lockout safety, and a wide operating range (-40 to 140°F). The RM7800E1010 carries UL, CSA, FCC, SRE, and FM approvals and includes a keyboard display module for easy system status indication, self-diagnostics, and trouble-shooting.

• Automatic burner sequencing and flame supervision for reliable ignition
• System status indication and self-diagnostic capabilities
• Pre-ignition and early spark termination to optimize startup
• Hardened interlock lockout for safety and compliance
• Versatile fuel support for gas/oil/coal or combination systems
