Honeywell Thermal Solutions FSG RM7838B1013 Burner Control

The Honeywell RM7838B1013 Burner Control, part of Honeywell Thermal Solutions, is a microprocessor-based integrated burner control designed for reliable semi-automatic programming and firing of single burners. This versatile unit handles pilot startup, flame establishment periods, and comprehensive self-diagnosis to ensure safe, efficient operation across gas, oil, coal, or combination fuel scenarios.

Key specifications include 120 Volt AC at 50/60 Hz, a compact 5 in W x 5-1/4 in D x 5 in H enclosure, and a pilot-type interrupted design with interlock lockout. With UL, CSA, FCC, CSD, SRE, and FM approvals, it is suitable for demanding industrial environments and a wide temperature range (-40 to 140°F in shipping and storage). The control supports pre-ignition sequencing, early spark termination, flame supervision, system status indication, and thorough self-diagnosis for troubleshooting.

• Type: Microprocessor-based integrated burner control
• Application: Industrial semi-automatic programmed firing for single burner systems
• Primary functions: Purge, burner pilot startup, flame supervision, pre-ignition, early spark termination
• Monitoring: System status indication, system/self-diagnosis and troubleshooting
• Electrical/physical: 120 VAC, 50/60 Hz; -40 to 140°F; 5" W x 5-1/4" D x 5" H
• Approvals: UL, CSA, FCC, CSD, SRE, FM
