Honeywell Thermal Solutions FSG RM7896A1012 Burner Control

The Honeywell RM7896A1012 Burner Control is a microprocessor-based, integrated controller designed for single-burner, on-off primary control applications. It delivers precise flame establishing periods of 4/10 second for the pilot and intermittent main firing, enabling rapid, reliable startup and safe operation.

Operating at 120 VAC (50/60 Hz), the unit fits a compact 5" W x 5-1/4" D x 5" H enclosure and is built for demanding environments. It supports automatic burner sequencing, flame supervision, system status indication, self-diagnostics, and built-in troubleshooting, with a selectable interlock type and a wide storage temperature range of -40 to 140°F.

• Application: Automatically fired gas/oil/combination fuel, single burner, on-off primary control
• Performance: Flame establishing period 4/10 second for pilot, intermittent main
• Electrical: 120 V AC, 50/60 Hz; compact 5" W x 5-1/4" D x 5" H
• Safety & Diagnostics: Flame supervision, system status indication, self-diagnostic, troubleshooting
• Interlocks & Approvals: Selectable interlock type; UL, CSA, FCC, SRE, FM approvals; storage -40 to 140°F
