Honeywell Thermal Solutions FSG V88J1006 High Temperature Diaphragm Gas Valve

The High Temperature Diaphragm Gas Valve from Honeywell Thermal Solutions, model FSG V88J1006, delivers precise, reliable control in demanding boiler and rooftop heater environments. This solenoid operated valve is Type NC with slow opening and fast closing action, a straight-through, non-offset design, and rugged 1 inch nominal size with threaded end connections (end-to-end distance 3-11/16 inches). The cast aluminum body is UL and CSA listed, rated for 32 to 150°F and up to 1 PSI. It supports Liquid Propane and Natural gas, and uses a 24V AC 60 Hz supply with 0.62 A current draw and 9 W power.

Overall dimensions are 4-5/16 inch width x 5 inch depth x 6-1/16 inch height. Mounting position is upright, and the valve connects via 6 inch lead wires, suitable for Atmospheric boiler and commercial water/rooftop heater installations.

• Nominal size: 1 inch
• End connections: Threaded x Threaded
• End-to-end distance: 3-11/16 inches
• Body material: Cast aluminum
• Temperature range: 32–150°F
• Pressure rating: 1 PSI
• Electrical: 24V AC, 0.62 A, 9 W
• Mounting position: Upright
• Lead wires: 6 inches
• Fuel types: Liquid Propane, Natural gas
• Applications: Atmospheric boiler, commercial water/rooftop heater
• Standards: UL, CSA
