Honeywell Thermal Solutions FSG V8944C1017 Diaphragm Gas Valve

Diaphragm Gas Valve delivers precise control for commercial boilers, makeup air systems, and rooftop heaters. The Honeywell FSG V8944C1017 Diaphragm Gas Valve is a 1-inch nominal size, 2-stage, slow-opening, straight-through, non-offset, solenoid-operated valve built with a die-cast aluminum body for reliable performance across HVAC and industrial applications.

Rated for -40 to 150°F and 1/2 psi, it operates on 24 VAC, 60 Hz, drawing 0.516 A and 12.4 VA. An automated position indicator supports quick status checks and seamless control integration. End connections are threaded x threaded, and the overall footprint measures 6 inches wide by 6 inches deep with a 6-9/16 inch height, mounting upright as required. Designed for liquid propane, this valve is well suited for atmospheric boilers, commercial water/makeup air, rooftop heaters, and duct furnaces. UL and CSA certified, it meets essential safety and performance standards for demanding HVAC environments.

• 2-Stage, Slow Opening, Straight-Through, Non-Offset valve design
• Nominal size 1 Inch; End connections: Threaded x Threaded
• Die-Cast Aluminum body with Automated position indicator
• Electrical: 24 VAC, 60 Hz; 0.516 A; 12.4 VA
• Valve timing: Open 3–25 seconds; Close 2 seconds
• Fuel: Liquid Propane; Applications: Atmospheric Boiler, Rooftop Heater, Duct Furnace
• UL listed / CSA approved for safety and compatibility
