ICM Controls ICM102B Time Delay Relay

ICM102B Time Delay Relay by ICM Controls is a dependable AC-operated timer designed for precise sequencing in control panels. It handles a wide contact voltage range of 18–240 VAC at 50/60 Hz and supports a contact current from 40 mA to 1.5 A, accommodating a variety of loads. The timing range of 0.03–10 minutes is adjustable using a user-friendly timing knob, with Delay-On-Make operation ensuring a controlled start after power is applied. This compact unit measures 2" x 2" x 1.25" and uses blade terminals for quick wiring. UL (Canada and US) and CSA approvals give confidence in safety and compatibility across North American installations. With an inrush current rating of 15 A, it's robust for inductive loads, motors, or heaters in automation projects. Ideal for fans, pumps, lights, or other processes that benefit from a reliable, timed delay in commercial and industrial environments.

• Type: AC operated time delay relay
• Timing range: 0.03–10 minutes (Delay-On-Make)
• Timing adjust: Knob control
• Voltage/current: 18–240 VAC @ 50/60 Hz; 40 mA–1.5 A
• Inrush: Up to 15 A
• Terminals: Blade terminals
• Approvals: UL (Canada/US) and CSA
• Dimensions: 2" L × 2" W × 1.25" H
