ICM Controls ICM102FB Time Delay Relay

The ICM102FB Time Delay Relay from ICM Controls is an AC-operated timing relay designed for precise delay-on-make sequencing in control panels. This versatile relay handles 18 to 240 VAC at 50/60 Hz and supports a wide timing range of 0.03 to 10 minutes, easily adjusted with a front-access knob.

• Timing mode: Delay-On-Make for controlled power-on sequencing.
• Adjustable timing: 0.03–10 minutes via a simple knob.
• Electrical ratings: 18–240 VAC coil/contacts; 40 mA to 1.5 A contact current.
• Construction: 2" L x 2" W x 1.25" H enclosure; terminal type 6-inch wire leads.
• Power handling: Inrush current up to 15 A.
• Certifications: UL (Canada and US) and CSA approvals.

With compact dimensions and a robust 15 A inrush capacity, the ICM102FB is ready for panel installations where reliable timing is essential. The combination of a knob-adjustable timer, wide voltage compatibility, and reputable safety approvals makes it ideal for automation tasks, process control, and equipment sequencing in North American systems.
