ICM Controls ICM104B Time Delay Relay

Introducing the ICM104B Time Delay Relay from ICM Controls, a compact AC/DC operated relay designed for precise delay-on-make timing in control circuits.

SPDT contact configuration (NO/NC) handles loads up to 20 A on the normally open contact and 10 A on the normally closed contact, with a contact voltage rating of 18-30 V AC at 50/60 Hz or 18-30 V DC.

The timing range runs from 10 to 1000 seconds and is adjustable via a front knob, delivering reliable Delay-On-Make operation for sequencing and interlock applications.

Blade terminals simplify wiring, and the unit carries UL (Canada and US) and CSA approvals for dependable performance in industrial environments.

Dimensions are 2 x 2 x 1.25 inches with a motor load rating of 2 HP (NO) or 1/2 HP (NC) at 120/240 V AC, making it a compact choice for control panels.

• AC/DC operated time delay relay with Delay-On-Make
• SPDT NO/NC contacts: 20 A (NO) / 10 A (NC)
• Adjustable timing: 10–1000 seconds via front knob
• Contact voltage: 18–30 V AC (50/60 Hz) or DC
• Blade terminals for quick wiring; compact enclosure
• UL and CSA approved for North American use
• 2 HP (NO) / 1/2 HP (NC) motor load at 120/240 V AC
