ICM Controls ICM203B Time Delay Relay

The ICM203B Time Delay Relay is an AC-operated timing control designed for reliable sequencing in automation and control panels. It handles 18–240 VAC at 50/60 Hz, delivering a flexible contact current range from 40 mA to 1 A to suit signaling or small-load switching. The timing range is 0.03 to 10 minutes and is adjustable with a front-panel knob, using the Delay-On-Make timing mode for predictable startup delays in machines and processes. With a compact 2" x 2" x 1.25" enclosure and blade terminals, it fits neatly into tight spaces and simplifies wiring. UL and CSA approvals ensure safety and compliance for both US and Canadian installations. Its robust inrush current rating of 15 A makes it suitable for inductive loads and short-term surges.

• ICM203B Time Delay Relay with adjustable 0.03–10 minute timing (knob controls) and Delay-On-Make operation
• AC operated input: 18–240 VAC, 50/60 Hz
• Contact current rating: 40 mA – 1 A; inrush current: 15 A
• Compact enclosure: 2" L × 2" W × 1.25" H; blade terminals for quick wiring
• UL and CSA approved for US and Canada; ideal for automation, control panels, conveyors, lighting, and HVAC timing
