ICM Controls ICM283 Gas Ignition Control

The ICM283 Gas Ignition Control is a microprocessor-based, hot surface ignition controller designed for natural gas or propane installations. This robust gas ignition control delivers reliable lighting and precise flame monitoring for gas-fired furnaces, boilers, and heating systems.

Key benefits include accurate flame sensing with single or dual rod configurations, adjustable ignition trial times of 4 or 7 seconds, and a 32-second prepurge for safe startup. It features a fast flame-failure response of 1.5 seconds, helping protect against unsafe operation. The unit drives a valve rated at 2 Amp at 24V and accepts power from 24/120V AC at 60 Hz with a 5 Amp, 120V output for the hot surface ignition element.

Designed for challenging conditions, its temperature range from -40 to 177 deg F ensures dependable performance in most environments. Typical applications include gas-fired furnaces, boilers, and heating systems where durable electronic ignition is essential.

• Fuel type: Natural or Liquid Propane Gas
• Ignition technology: Hot Surface Ignition with flame sense
• Flame sensing: Single or Dual Rod
• Ignition timing: 4 or 7 second trial; 32 second prepurge
• Electrical: Valve 2 Amp @ 24V; Input 24/120V AC @ 60 Hz; Output 5 Amp @ 120V
• Physical size: 4" L x 5.375" W x 1.625" H; Temp range -40 to 177°F
• Applications: Gas Fired Furnace, Boiler, Heating systems
