ICM Controls ICM292 Furnace Control Module

The ICM292 Furnace Control Module is a microprocessor-based control designed for direct spark ignition in modern gas furnaces. This rugged unit governs natural and propane gas with a precise 24V AC control signal, delivering reliable startup, safe flame monitoring, and intuitive system diagnostics.

Powerful yet compact, this control supports 24 Volt AC control (18–30 VAC) and 115 VAC line power, with a wide operating temperature range from -40 to 176°F for dependable performance in varied climates. Key specifications include a compact enclosure and essential safety approvals for reliable operation.

Designed for seamless integration with inducer motors, air cleaners, humidifiers, spark igniters, and gas valves, it ensures reliable ignition and flame safety. Ignition trial time is 7 seconds, with a 30-second prepurge to prevent fuel buildup and maximize comfort and efficiency. LED indicators provide quick status at a glance.

• Microprocessor-based control with Direct Spark Ignition for reliable ignition and flame monitoring.
• Supports Natural Gas and Propane (LPG) fuels.
• Ignition trial time: 7 seconds; Prepurge: 30 seconds.
• Power: 24V AC control (18–30 VAC), 115V AC line; low power consumption (0.3 A plus gas valve current).
• Compact size: 5.75" L × 6.625" W × 2.5" H; Temperature range -40 to 176°F.
• Applications: Inducer motor, air cleaner, humidifier, spark igniter, and gas valve.
• Approvals: UL (Canada and US), CSA.
• LED indicators: PWR (green), OK (green), FLAME (yellow).
