Johnson Controls F263MAC-V01C Liquid Level Float Switch

Liquid Level Float Switch from Johnson Controls is engineered for dependable tank level sensing, with the F263MAC-V01C model delivering rugged performance in demanding environments.

Designed for industrial use, this 1 inch nominal size switch features a threaded end connection and SPDT contact for flexible control.

Its robust NEMA 4 enclosure protects internal components in wet or dusty settings, while copper enclosure and copper sensor material provide corrosion resistance. The device operates across a wide range: -40 to 140°F ambient and -20 to 250°F process temperatures, with a 100 PSIG pressure rating. UL, CE, FCC, and RCM standards ensure reliable compliance in diverse markets.

Key features

• Nominal Size: 1 Inch
• End Connection: Threaded
• Contact Type: SPDT
• Enclosure Type: NEMA 4
• Enclosure Material: Copper
• Sensor Material: Copper
• Wiring Connection: 3 color-coded screws + 1 Ground
• Temperature Rating: -20 to 250°F
• Ambient Temperature Range: -40 to 140°F
• Pressure Rating: 100 PSIG
• Standards: UL, CE, FCC, RCM
