Johnson Controls HE-69135NS-0 Humidity Element and Temperature Sensor

The Johnson Controls HE-69135NS-0 Humidity Element and Temperature Sensor delivers precise humidity and temperature readings in a compact 3" W x 1.23" D x 3" H package. This humidity element and temperature sensor uses a thin film nickel temperature sensor for stable, long-term performance in HVAC environments.

Designed for rooftop units and retrofit projects, it offers flexible power and easy wiring. It accepts an input voltage of 14-30 VDC or 20-30 VAC and provides a 5 VDC output, up to 25 mA. With an accuracy of +/-3%, a full operating range of 0-60°C and 0-100% RH, it covers most commercial HVAC needs. The unit mounts on a surface and uses 1/4" male spade terminals, with a 50/60 Hz frequency rating.

• All-in-one humidity sensor and temperature sensor for HVAC applications
• Thin film nickel temperature element for fast response
• Wide power input: 14–30 VDC or 20–30 VAC with 5 VDC output
• Output current up to 25 mA (minimum 3 mA) at 5 VDC
• Operating range: 0–60°C and 0–100% RH with +/-3% accuracy
• Surface-mount design with 1/4" male spade terminals; supports 50/60 Hz
• Compact footprint: 3" W x 1.23" D x 3" H; wiring 16–24 AWG
