Johnson Controls M9116-HGA-2 Electric Damper Actuator

The Johnson Controls M9116-HGA-2 Electric Damper Actuator provides precise damper control for HVAC systems. This Electric Damper Actuator features Type Proportional Adjustable Start and Span, delivering accurate positioning for energy-efficient airflow.

Operating at 24 Volt AC/DC with a 50/60 Hz rating, it offers reliable performance in non-spring return configurations and robust protection with a NEMA 2/IP42 enclosure. The compact 4.2"W x 2.68"D x 6"H body fits tight spaces while handling demanding HVAC environments.

• Type: Proportional Adjustable Start and Span
• Voltage: 24 VAC/DC; Frequency: 50/60 Hz; Power: 7.5 VA
• Torque: 140 in-lb; Rotation: 90 degrees
• Enclosure: NEMA 2, IP42
• Shaft options: 3/8–3/4 in round; 3/8–5/8 in square
• Application: HVAC system damper control
• Approvals: UL, CSA, CE

Key features for installers include non-spring return operation and straightforward integration with standard HVAC dampers, ensuring dependable performance across commercial and industrial applications.
