Johnson Controls M9208-BGC-3 Electric Actuator

The Johnson Controls M9208-BGC-3 electric actuator delivers precise, reliable On/Off control for HVAC systems. This spring-return actuator operates at 24 Volt AC/DC with a 95° rotation and 70 in‑lb torque, ensuring robust performance across a range of dampers and valves.

Configured for durable, ready-to-use installation, it features a NEMA 2 enclosure and IP54 protection, making it suitable for challenging environments. The unit’s compact footprint measures 3.9" W x 2.26" D x 6.33" H, with a shaft that accepts 5/16" to 5/8" round or 1/4" to 1/2" square configurations. A 3/8" flexible metal conduit supply connection simplifies wiring in HVAC control panels.

Key specs include 50/60 Hz operation, and power requirements of 6.1 VA running / 1.2 VA holding at 24V AC or 3.5 W running / 0.5 W holding at 24V DC. Approved for safety and compatibility with UL and CE standards, this actuator is designed for dependable, long‑term HVAC control.

• On/Off type with spring return
• Wide voltage compatibility: 24V AC/DC
• High torque: 70 in-lb
• Angle of rotation: 95 degrees
• Rugged enclosure: NEMA 2, IP54
• Compact dimensions and versatile shaft sizing
• UL and CE approvals for industry compliance
